JIAOTAOTAO Thermally Conductive Adhesive Tape - 0.25 W/m·K

Thermally Conductive Adhesive Tape

Thermally Conductive Adhesive Tape Overview

Thermally conductive adhesive tape JTT-TD250 is designed for efficient heat transfer and secure bonding in electronic and industrial thermal management applications. Thermally conductive adhesive tape combines stable adhesion with reliable thermal conductivity, allowing components to dissipate heat while remaining firmly fixed.

As a professional manufacturer, we produce thermally conductive adhesive tape using acrylic adhesive blended with ceramic fillers to achieve balanced thermal performance and mechanical strength. Thermally conductive adhesive tape JTT-TD250 is suitable for continuous operation in demanding environments where heat dissipation and electrical insulation are both required.

Thermally conductive adhesive tape is widely used as an alternative to thermal grease or mechanical fastening. With controlled thickness and uniform coating, thermally conductive adhesive tape supports consistent thermal paths between heat-generating components and heat sinks.

Technical Specifications of Thermally Conductive Adhesive Tape

Thermally conductive adhesive tape JTT-TD250 is manufactured under factory-controlled conditions to meet industrial application requirements.

• Material: Acrylic adhesive with ceramic filler

• Color:White

• Total Thickness: 0.25 mm

• Thermal Conductivity: 0.25 W/m·K

• Adhesion (180°): 1.5 kgf / 24 mm

• Tensile Strength: 1400 g / 24 mm

• Holding Power: ≥ 24 hours

• Elongation:28.5%

• Dielectric Strength: 2.0 kV

• Temperature Resistance: -40°C to +150°C

• Customization / OEM: Width, length, liner, and roll size available on request

Each batch of thermally conductive adhesive tape is tested for thermal conductivity, adhesion performance, and dielectric strength to ensure stable quality for industrial use.

Applications of Thermally Conductive Adhesive Tape

Thermally conductive adhesive tape is widely applied in heat dissipation and electronic assembly scenarios:

• Thermally conductive adhesive tape for LED module heat sinking

• Thermal conductive tape for power supply and inverter components

• Thermally conductive adhesive tape for CPU, chipset, and IC thermal management

• Heat dissipation adhesive tape for aluminum heat sink bonding

• Thermally conductive adhesive tape for automotive electronics and control units

• Thermal management tape for battery packs and charging modules

• Thermally conductive adhesive tape for industrial electronic assemblies

In these applications, thermally conductive adhesive tape provides stable thermal transfer while maintaining secure mechanical bonding.

Thermally Conductive Adhesive Tape Manufacturing Capability

As a dedicated thermally conductive adhesive tape manufacturer, we operate a factory focused on industrial thermal interface materials.

• Manufacturer direct production of thermally conductive adhesive tape with controlled ceramic filler dispersion

• Factory-managed acrylic adhesive formulation to ensure stable thermal conductivity

• In-house coating, curing, slitting, and rewinding for dimensional accuracy

• Direct factory supply supporting OEM projects and bulk industrial orders

• Manufacturer quality control covering thermal conductivity, adhesion, and dielectric testing

• Stable production capacity to ensure continuous supply of thermally conductive adhesive tape

Our manufacturer-level processes ensure batch-to-batch consistency and reliable thermal performance for industrial customers.

Product Advantages Compared with Traditional Thermal Interface Materials (TIM)

Packaging & Customization

✔ Custom widths (5mm–500mm)
✔ Custom die-cut shapes available for OEM/ODM orders
✔ Roll, sheet, kiss-cut sheet, and pre-cut formats
✔ Neutral or JIAOTAOTAO-branded packaging

How to Use JTT-TD250

1. Clean both bonding surfaces (metal, PCB, plastic).

2. Remove release liner.

3. Apply uniform pressure to ensure full contact.

4. Allow 12–24 hours for optimal adhesive strength.

5. Avoid re-positioning after application.

Simple. Clean. Reliable. Perfect for professional electronics assembly.

FAQ

Q1: Is JTT-TD250 safe for electronic components?

Yes. It is electrically insulating and thermally conductive, making it ideal for bonding sensitive components.

Q2: Does it replace thermal paste?

Yes, in most applications. Unlike pastes, it provides structural bonding and consistent thickness.

Q3: Can it be die-cut into small custom shapes?

Absolutely. We support OEM die-cutting for mass production.

Q4: What is the recommended operating temperature?

-40°C to +150°C, making it a true Heat-Resistant Double-Sided Adhesive Tape.

Q5: What is the maximum roll width?

Standard up to 500 mm, customizable on request.

Contact Thermally Conductive Adhesive Tape Manufacturer

Contact us now for thermally conductive adhesive tape JTT-TD250 quotations, samples, and technical support. As a professional manufacturer, we provide factory direct thermally conductive adhesive tape with stable quality and customization options.

Reach our manufacturer team to discuss thermally conductive adhesive tape specifications, OEM requirements, and long-term supply cooperation.
