JIAOTAOTAO JTT01-25100D-Silicone Double Sided Adhesive Tape 0.10mm

JTT01-25100D

Total Thickness mm 0.10
Adhesive Type — Silicone (Double-Sided)
Backing Material — Polyimide Film
Color — Amber
Adhesion to Steel N/25 mm 8.0
Tensile Strength N/25 mm 130
Elongation at Break % 55
Temperature Resistance °C -73 ~ 260
Dielectric Strength kV ≥6.5

Quantity:

Contact Now

High Temperature Double Sided Polyimide Adhesive Tape 0.10mm JTT01-25100D

Silicone Double Sided Adhesive Tape

Product Overview

Silicone double sided adhesive tape JTT01-25100D is a high temperature insulation bonding material designed for electronic and electrical applications. This silicone double sided adhesive tape uses silicone adhesive on both sides and a polyimide film backing to ensure stable performance under extreme heat.
As a manufacturer, we produce silicone double sided adhesive tape JTT01-25100D for industrial bonding, insulation, and fixing processes where standard adhesive tapes cannot perform. This silicone double sided adhesive tape is supplied directly from factory production lines with consistent quality control.

Silicone Double Sided Adhesive Tape Technical Specifications

Material: Polyimide film with silicone adhesive on both sides
Total Thickness: 0.10 mm
Adhesive Type: Silicone (Double-Sided)
Color: Amber
Adhesion to Steel: 8.0 N/25 mm
Tensile Strength: 130 N/25 mm
Elongation at Break: 55%
Temperature Resistance: -73°C to 260°C
Dielectric Strength: ≥ 6.5 kV
Customization / OEM: Width, length, die-cut shapes available from manufacturer factory

This silicone double sided adhesive tape maintains adhesion stability during thermal cycling and high-temperature processing.

Technical Specifications

Property	Unit	Typical Value	Test Method
Total Thickness	mm	0.10	ASTM D3652
Adhesive Type	—	Silicone (Double-Sided)	—
Backing Material	—	Polyimide Film	—
Color	—	Amber	Visual
Adhesion to Steel	N/25 mm	8.0	ASTM D3330
Tensile Strength	N/25 mm	130	ASTM D3759
Elongation at Break	%	55	ASTM D3759
Temperature Resistance	°C	-73 ~ 260	ASTM D3330
Dielectric Strength	kV	≥6.5	ASTM D149

Silicone Double Sided Adhesive Tape Applications

Silicone double sided adhesive tape for electronics insulation bonding
Silicone double sided adhesive tape used in PCB assembly and component fixing
Silicone double sided adhesive tape for lithium battery insulation layers
Silicone double sided adhesive tape for polyimide silicone tape lamination
Silicone double sided adhesive tape in high temperature double sided tape processes
Silicone double sided adhesive tape for heat resistant adhesive tape requirements

Silicone Double Sided Adhesive Tape Manufacturing Capability

Manufacturer with dedicated silicone double sided adhesive tape coating lines
Factory direct supply of silicone double sided adhesive tape without intermediaries
Manufacturer controlled thickness tolerance for silicone double sided adhesive tape
Factory supports custom slitting and die-cutting for silicone double sided adhesive tape
Manufacturer production meets electronics industry insulation standards

We supply silicone double sided adhesive tape directly from factory for stable batch consistency.

FAQ — High Temperature Double Sided Polyimide Adhesive Tape 0.10mm

Q1: What makes this high temperature double sided polyimide adhesive tape suitable for electronics?

A1: It combines high dielectric strength and silicone adhesion, ensuring reliability under heat and voltage stress.

Q2: Can JTT01-25100D be used for reflow or soldering applications?

A2: Yes, the tape endures up to 260 °C, ideal for reflow solder and powder coating protection processes.

Silicone Double Sided Adhesive Tape Inquiry and Contact

For silicone double sided adhesive tape JTT01-25100D manufacturer direct supply, please contact us for specifications, samples, and bulk pricing.
As a manufacturer, we provide silicone double sided adhesive tape for long-term industrial cooperation and OEM projects.
