Product Overview

Double sided silicone adhesive tape is the industrial bonding material supplied on this page. This double sided silicone adhesive tape is produced directly by us as a manufacturer and factory focused on silicone-based pressure sensitive adhesive products.
As a manufacturer and factory, we supply double sided silicone adhesive tape designed specifically as double sided tape that sticks to silicone under high temperature and electrical insulation conditions.

Double sided silicone adhesive tape is coated, laminated, and slit entirely in our factory, and all specifications are supplied directly from manufacturer production without trading intermediaries.

Designed for insulation, metal lamination, and electronic assembly requiring strong adhesion and temperature endurance.

Technical Specifications

Material

• Adhesive type: Silicone adhesive (both sides)

Thickness / Size

• Total thickness: 0.08 mm

• Width: factory slitting available

• Length: industrial roll formats

Temperature Resistance

• Long-term operating temperature: 180°C

• Short-term temperature resistance: 220°C

Adhesive Type

• Silicone pressure-sensitive adhesive

• Peel strength: 900–1100 g / 25 mm

• Holding power: ≥ 24 hours

Electrical & Mechanical Properties

• Tensile strength: ≥ 120 N / 25 mm

• Dielectric strength: 7 kV / mm

• Flame rating: UL94 VTM-2

Customization / OEM

• Width and roll length customization by factory

• Core size and packaging OEM support

• Batch-controlled production from manufacturer

Key Features

• High bond strength: Peel adhesion 900–1100 g/25 mm for secure fixation.
• Excellent heat resistance: Long-term 180 °C, short-term 220 °C.
• Thin PET base: 0.08 mm for precision lamination and cutting.
• High dielectric strength: 7 kV/mm insulation capability.
• UL94 VTM-2 certified: Flame retardant and RoHS compliant.

Applications

• Double sided silicone adhesive tape for bonding silicone rubber components

• Double sided tape that sticks to silicone used in gasket fixation

• Silicone double sided tape for electrical insulation assembly

• High temperature silicone adhesive tape for heater and sensor mounting

• Double sided silicone adhesive tape as 3m double sided silicone tape alternative

• Electrical insulation silicone tape for industrial component bonding

Why Choose JIAOTAOTAO Double Sided Silicone Adhesive Tape

• We operate as a manufacturer with dedicated silicone adhesive coating lines

• Factory production ensures consistent adhesion for double sided silicone adhesive tape

• Manufacturer direct supply supports stable peel strength and holding power

• Factory controls curing, lamination, and slitting processes internally

• Manufacturer supports UL94 VTM-2 compliant silicone adhesive tape batches

• Factory-based production avoids mixed specifications and trading variations

All double sided silicone adhesive tape is supplied under factory-level process control for industrial B2B use.
