High Temp Polyimide Tape 0.08mm
High Temp Polyimide Tape 0.08mm
High Temp Polyimide Tape 0.08mm is a polyimide film adhesive tape designed for electronic insulation, PCB masking, and high temperature industrial processing. It combines good dielectric performance, dimensional stability, and residue-controlled removal in suitable applications. Standard roll size is 50 mm × 50 m, and customized widths, lengths, die-cut parts, and converted formats are available for OEM and industrial supply projects.
What is High Temp Polyimide Tape 0.08mm?
High Temp Polyimide Tape 0.08mm is a pressure-sensitive tape made from polyimide (PI) film backing coated with a high temperature adhesive system for demanding industrial and electronic applications. It is commonly used where heat resistance, electrical insulation, clean masking performance, and process stability are required. Compared with general-purpose masking tapes, this PI film adhesive tape is more suitable for PCB manufacturing, electronic component protection, transformer insulation, and production processes involving elevated temperatures.
Polyimide Tape Model List
Product Introduction
Core Advantages
- Polyimide film backing
Provides high temperature stability, good dielectric strength, and reliable dimensional performance for industrial insulation and masking processes. - High temperature adhesive system
Supports stable adhesion during production and controlled removal in suitable masking applications. - 0.08 mm total thickness
A practical thickness for electronic insulation, PCB process protection, and converted die-cut parts where handling stability is required. - Heat resistance performance
Suitable for demanding production environments. Short-term process resistance can reach up to 260°C depending on substrate, dwell time, and operating conditions. - Standard industrial roll size
Standard specification: 50 mm × 50 m. Width, length, core size, and converted formats can be customized for OEM supply.
Typical Applications
- PCB wave solder masking
- Reflow process protection
- Electronic component insulation
- Transformer and motor coil insulation
- Gold finger masking and temporary protection
- Battery pack insulation and fixing
- Sensor, terminal, and connector protection
- Precision die-cut insulation parts
Product Advantages
- Stable performance in high temperature manufacturing environments
- Suitable for insulation, masking, and process protection
- Good dielectric properties and dimensional stability
- Residue-controlled removal in matched applications
- Supports slitting, die cutting, and OEM converting service
- Suitable for industrial electronics, electrical assembly, and precision manufacturing
Customized Service
1. Size Customization
- Width customization
- Length customization
- Roll diameter customization
- Core size customization
2. Material / Structure Options
- Different PI film thickness selections
- Release liner option
- Single roll, log roll, or sheet format
- Custom die-cut insulation parts
3. Packaging Customization
- Label customization
- OPP bag
- PVC box
- Carton
- Custom export packaging
4. Supply Capability
- Jumbo roll supply
- Log roll supply
- Precision slitting service
- OEM / ODM converting support
FAQ — High Temp Polyimide Tape 0.08mm
Q1 | What is High Temp Polyimide Tape 0.08mm used for?
It is mainly used for PCB masking, electronic insulation, high temperature process protection, transformer insulation, and precision industrial manufacturing applications.
Q2 | Can this tape withstand 260°C?
It is designed for high temperature applications. Short-term resistance can reach up to 260°C depending on the substrate, dwell time, and actual process conditions. Application testing is recommended before mass use.
Q3 | Is it suitable for electronic insulation?
Yes. Polyimide film tape is widely used in electronics and electrical assembly because of its insulation performance, dimensional stability, and heat resistance.
Q4 | What is the standard size of this product?
The current standard size is 50 mm × 50 m with a total thickness of 0.08 mm. Custom widths, lengths, and roll formats are available for OEM orders.
Q5 | Does it leave residue after removal?
In suitable masking and protection applications, the tape is designed for controlled and clean removal. Final performance depends on temperature, dwell time, and substrate compatibility.
Q6 | Can you provide die-cut parts?
Yes. We can supply slitted rolls, kiss-cut parts, die-cut insulation pieces, and other converted formats based on customer drawings or application requirements.
Q7 | What adhesive system is used?
This product uses a high temperature pressure-sensitive adhesive system designed for industrial processing. Adhesive construction can be adjusted according to specific application requirements.
Q8 | Can I customize thickness or packaging?
Yes. Thickness structure, roll size, core size, release liner, labels, and export packaging can be customized for industrial procurement and production projects.
Q9 | Are samples and bulk supply available?
Yes. Sample support and bulk production are available. Please contact JIAOTAOTAO through the inquiry page for specification confirmation and quotation.
Need help choosing the right industrial tape?
Send us your application details, including temperature, surface material, size, quantity and current problem. Our team will help recommend a suitable tape material or custom die-cut solution.
