What Is Thermal Tape?
Thermal tape (also referred to as thermally conductive adhesive tape) is a double-sided pressure-sensitive tape constructed with a thermally conductive filler-loaded polymer carrier—typically a fiberglass mesh, acrylic film, or polyimide film—coated on both sides with a thermally and electrically conductive or insulating adhesive system. At 0.20 mm total thickness, it bonds heat-generating components such as power semiconductors, LED modules, and motor drivers directly to heatsinks or chassis ground planes, replacing mechanical fasteners and thermal grease in applications where permanent, uniform bondline thickness and electrical isolation are required. Thermal conductivity ranges from 1.0 to 3.0 W/m·K depending on filler loading and carrier construction.
Quick Facts
- Product form: Double-sided thermally conductive adhesive tape, 0.20 mm thickness
- Carrier / backing: Thermally conductive acrylic film or fiberglass-reinforced polymer matrix
- Adhesive system: Thermally conductive pressure-sensitive acrylic (both sides)
- Thermal conductivity: ≥ 1.0 W/m·K (standard); up to 3.0 W/m·K (high-conductivity grade)
- Dielectric strength: ≥ 3,000 V (electrically insulating grade, per ASTM D1000)
- Operating temperature: –40°C to +150°C continuous
- Core industrial uses: LED strip & module bonding, PCB power component mounting, IGBT / MOSFET heatsink attachment, battery pack thermal management, motor driver modules
- Standard thickness: 0.20 mm; custom 0.10–1.00 mm available
Technical Specifications & Material Science
Construction: How 0.20 mm Thermal Tape Transfers Heat
A 0.20 mm thermal tape cross-section comprises three functional layers: two thermally conductive pressure-sensitive adhesive layers (typically 70–90 µm each) bonded to a central thermally conductive carrier film (20–60 µm). The adhesive layers contain aluminum oxide (Al₂O₃), boron nitride (BN), or aluminum nitride (AlN) filler particles dispersed in an acrylic or silicone matrix. Filler particle size and loading percentage (typically 60–80 wt%) directly govern thermal conductivity—higher loading increases conductivity but reduces conformability and adhesion to rough surfaces.
The bondline thickness control achieved by tape (±0.02 mm at 0.20 mm nominal) is its primary advantage over thermal grease in production environments. Thermal grease bondline thickness varies with application pressure, operator technique, and pump-out over time, leading to thermal resistance variation across a production batch of ±30% or more. Tape eliminates this variability.
Electrical isolation is a critical secondary function. Most thermal tape constructions provide dielectric strength ≥3,000 V, electrically isolating the component from the heatsink chassis—essential where the heatsink is chassis ground and the component drain/collector pad is at switching voltage potential. Verify the specific grade's dielectric rating against the application's working voltage plus appropriate safety margins per IEC 60664-1 creepage and clearance requirements.
Standard Technical Parameters — JTT-Tape Thermal Conductive Tape (0.20 mm)
| Parameter | Value | Test Standard |
|---|---|---|
| Total Thickness | 0.20 mm ± 0.02 mm | ASTM D1000 |
| Adhesive Type | Thermally conductive acrylic PSA (both sides) | — |
| Thermal Conductivity | ≥ 1.0 W/m·K (standard grade) ≥ 2.0 W/m·K (high-conductivity grade) |
ASTM E1530 |
| Thermal Resistance (at 0.20 mm) | ≤ 0.20 cm²·K/W (standard grade) | ASTM D5470 |
| Dielectric Strength | ≥ 3,000 V | ASTM D149 / UL 510 |
| Volume Resistivity | ≥ 1 × 10¹² Ω·cm | ASTM D257 |
| Operating Temperature Range | –40°C to +150°C | IEC 60454-2 |
| Adhesion to Aluminum (180° Peel) | ≥ 6 N/25 mm | PSTC-101 |
| Tensile Strength | ≥ 20 N/25 mm | ASTM D1000 |
| Flame Retardancy | UL94 V-0 | UL 94 |
| Standard Width Range | 5–1,000 mm (custom slit) | — |
| Available Thickness Options | 0.10 / 0.15 / 0.20 / 0.25 / 0.30 / 0.50 / 1.00 mm | — |
| Shelf Life | 12 months (5–25°C, RH ≤ 60%, original packaging) | — |
Industrial Applications
1. LED Module & Strip Bonding to Heatsinks
High-power LED COB arrays and rigid LED strips generate junction temperatures that must be managed within Tj ≤ 85–105°C to maintain lumen output and rated lifespan (L70 at 50,000 hours). Thermal tape at 0.20 mm provides a controlled, repeatable bondline between the LED MCPCB and the extruded aluminum heatsink, without the squeeze-out contamination risk of thermal grease on LED optics or PCB traces. In automated LED assembly lines, tape-die-cut pads can be dispensed and applied robotically at throughputs exceeding 1,000 units/hour—a process impossible with paste-form thermal interface materials.
2. Power Semiconductor Heatsink Attachment (IGBT / MOSFET / Diode)
IGBT modules in variable frequency drives and inverters dissipate 50–500 W continuously. Mounting to aluminum or copper heatsinks via thermal tape eliminates the torque-variation problem inherent in spring-clip or screw-mount configurations, where uneven clamping force creates high-resistance air pockets. Tape also provides electrical isolation between the device baseplate (switching potential) and chassis-grounded heatsink, with dielectric strength ≥3,000 V meeting the isolation requirements of IEC 61800-5-1 for motor drive equipment up to 600 V working voltage.
3. PCB Component Thermal Management
Voltage regulators, DC-DC converter ICs, and linear regulators on dense PCB assemblies frequently exceed their junction temperature ratings when relying solely on PCB copper pour for heat spreading. Attaching a small aluminum or copper heatsink via 0.20 mm thermal tape reduces thermal resistance by 30–60% compared to double-sided foam tape (λ ≈ 0.04 W/m·K) used as an adhesive substitute. The tape's thin profile (0.20 mm vs. 1.00–3.00 mm for foam tape) also preserves PCB-to-component clearances in compact enclosures.
4. Battery Pack & Energy Storage Thermal Management
Lithium-ion cell packs in EV battery modules and stationary storage systems require inter-cell thermal management to prevent thermal runaway propagation. Thermal tape applied between cells and cooling plates or between cell groups and aluminum separator frames provides both thermal coupling (conducting heat to the cooling circuit) and electrical isolation between cells at different state-of-charge voltages. The tape's compressibility accommodates cell swelling of 1–3% during charge-discharge cycles without debonding.
5. Motor Driver & Inverter Module Assembly
Three-phase motor driver modules in industrial automation, robotics, and HVAC systems combine multiple power devices (IGBTs, gate drivers, current sensors) on a single substrate. Bonding this substrate to a cold plate or finned heatsink via thermal tape standardizes the assembly process across production shifts and eliminates torque spec non-conformances on fastened assemblies. At 0.20 mm, thermal resistance contribution from the tape itself is ≤0.20 cm²·K/W—acceptable for most motor drive power density levels below 200 W/cm².
Thermal Tape vs Thermal Pad vs Thermal Grease: How to Choose
Three thermal interface material (TIM) categories dominate industrial thermal management. Selection depends on power density, bondline control requirements, reworkability, and production process constraints.
| Parameter | Thermal Tape (0.20 mm, JTT-Tape) |
Thermal Pad (Phase-change / Silicone) |
Thermal Grease (Paste) |
|---|---|---|---|
| Thermal Conductivity | 1.0–3.0 W/m·K | 3.0–8.0 W/m·K | 3.0–12.0 W/m·K |
| Bondline Control | ±0.02 mm (precise) | ±0.05–0.10 mm | Variable (operator-dependent) |
| Adhesive Bond | Yes — permanent PSA | No (mechanical hold required) | No (mechanical hold required) |
| Electrical Isolation | ✓ ≥ 3,000 V | ✓ ≥ 3,000 V (insulating grade) | ⚠ Grade-dependent |
| Reworkability | Limited (permanent bond) | Good | Excellent |
| Automation Compatibility | Excellent (die-cut pads) | Moderate | Good (dispense robots) |
| Pump-Out Risk | None | Low | High (over thermal cycles) |
| Unit Cost (relative) | Low–Medium | Medium–High | Low (material only) |
| Best For | LED, PCB heatsink, battery, motor driver | High-power IGBT, reworkable assemblies | Maximum thermal performance, R&D, rework |
Selection rule: Where bondline precision, automated assembly, permanent adhesive bond, and electrical isolation are simultaneously required—LED manufacturing, battery pack assembly, PCB heatsink attachment—0.20 mm thermal tape is the optimum TIM format. Where maximum thermal conductivity (>5 W/m·K) is the overriding requirement and mechanical fasteners provide clamping force, thermal grease or high-conductivity phase-change pads should be evaluated. For field-service reworkable assemblies, non-adhesive thermal pads with mechanical retention are preferred.
Customization & Supply Capabilities
JTT-Tape thermal conductive tape is manufactured by JIAOTAOTAO New Materials Co., Ltd. (Dongguan, Guangdong), established 2009. Production capacity: 8 automated coating lines, 6,000 m² facility. Certifications: ISO 9001:2015, SGS, UL94 V-0. The following custom supply capabilities are available direct from the manufacturer:
- Thickness Options: 0.10 mm / 0.15 mm / 0.20 mm / 0.25 mm / 0.30 mm / 0.50 mm / 1.00 mm. Non-standard thicknesses on request.
- Custom Width Slitting: 5 mm to 1,000 mm, tolerance ±0.5 mm. Slit from jumbo master rolls for volume orders.
- Die-Cut Pads: Custom pad shapes, frames, and arrays for automated pick-and-place or manual assembly. Tolerance ±0.2 mm. Kiss-cut on liner for peel-and-stick application.
- Thermal Conductivity Grades: Standard (≥1.0 W/m·K), High-Conductivity (≥2.0 W/m·K), Ultra (≥3.0 W/m·K). Specify based on power density and heatsink thermal resistance.
- Liner Options: Single-liner (one-side release), double-liner (sequential peel), polyester liner (for flatness in die-cut pads).
- OEM / Private Label: Custom reel labeling, carton marking, and co-branding for distributor programs.
- Free Qualification Samples: Up to 3 configurations dispatched within 5 business days. Specify substrate type (aluminum / copper / FR4) and power dissipation for grade recommendation.
- MOQ: 1 carton for standard slit rolls. Die-cut tooling: one-time setup fee, then no additional MOQ premium.
- Lead Time: Standard thickness / standard widths: 7–15 business days. Custom die-cut or non-standard thickness: 15–25 business days.
FAQ for Engineers & Procurement
Q1: What thermal conductivity does 0.20 mm thermal tape provide, and is it sufficient for LED or power module applications?
Standard grade JTT-Tape thermal tape provides ≥1.0 W/m·K, yielding a thermal resistance of ≤0.20 cm²·K/W at 0.20 mm thickness. For LED modules dissipating ≤5 W/cm² and PCB heatsink attachments, this is sufficient. Power modules dissipating >10 W/cm² should specify the high-conductivity grade (≥2.0 W/m·K) or evaluate 0.10 mm thickness for lower thermal resistance. Always calculate total junction-to-ambient resistance to verify adequacy for the specific power budget.
Q2: Does thermal tape provide electrical isolation between the component and heatsink?
Yes. JTT-Tape thermal conductive tape (electrically insulating grade) provides dielectric strength ≥3,000 V per ASTM D149 and volume resistivity ≥1×10¹² Ω·cm per ASTM D257. This isolates switching-node potentials from chassis-grounded heatsinks in motor drives, inverters, and power supplies operating at up to 600 V working voltage (verify with IEC 60664-1 for specific creepage requirements). Note: electrically conductive thermal tape grades exist for EMI shielding—confirm the grade specified is the insulating version.
Q3: Why choose 0.20 mm thermal tape over thermal grease for production assembly?
Thermal grease bondline thickness varies with applied pressure and operator technique, creating thermal resistance variation of ±30% or more across a production batch. Over thermal cycling, grease undergoes pump-out—migrating laterally from the bondline—increasing thermal resistance by 50–200% over product lifetime. Thermal tape eliminates both failure modes: bondline is fixed at 0.20 mm ±0.02 mm, grease pump-out is not possible, and the adhesive bond eliminates the mechanical fastener entirely in low-to-medium clamping force applications.
Q4: What is the maximum operating temperature of thermal tape, and can it be used in automotive applications?
JTT-Tape thermal conductive tape is rated for –40°C to +150°C continuous operating temperature. This covers automotive underhood ambient conditions (IEC 60068-2, AEC-Q200 reference), where long-term ambient temperatures at ECU mounting locations reach 105–125°C. For direct power device baseplate attachment (junction temperatures to 175°C), verify that the interface temperature at the tape surface remains within the 150°C continuous rating. Applications requiring 175°C+ continuous should evaluate high-temperature silicone-adhesive thermal tape constructions.
Q5: Can thermal tape be die-cut into custom pad shapes for automated assembly?
Yes. JTT-Tape thermal tape is available as custom die-cut pads in any shape—rectangular, circular, complex outlines—with tolerance ±0.2 mm and kiss-cut on silicone liner for peel-and-stick manual or robotic application. Arrays of pads on a roll are available for pick-and-place automation. Standard IGBT footprint pads (e.g., TO-247, TO-3P, D²PAK, SOT-227) are common configurations. Tooling setup requires a one-time die cost; no minimum order quantity per subsequent run.
Q6: How should thermal tape be stored, and what is its shelf life?
Store at 5–25°C, relative humidity ≤60%, in original sealed packaging, away from UV sources and ozone-generating equipment. Do not compress rolls under heavy loads—the thermally conductive filler particles are harder than the adhesive matrix and can cause surface impression on adjacent liner. Shelf life: 12 months from manufacturing date under stated conditions. Rolls approaching shelf life should be adhesion-tested on the target substrate before use in production.
Q7: How does JTT-Tape thermal tape compare to 3M 8805 / 8810 or Bergquist GP3000 series?
3M 8805 (0.13 mm, 0.9 W/m·K) and 3M 8810 (0.25 mm, 0.9 W/m·K) are acrylic-adhesive thermal tapes in the same product category. Bergquist GP3000 series provides higher conductivity (3.0 W/m·K) in thicker constructions. JTT-Tape's 0.20 mm standard grade (≥1.0 W/m·K) bridges these specifications at direct-factory pricing, with full OEM slitting and die-cut capability unavailable through distribution channels. For conductivity-matched specifications, JTT-Tape's high-conductivity grade (≥2.0 W/m·K) at 0.20 mm offers a cost-competitive alternative to Bergquist and Laird equivalents.
